D3 All-in-one Solar Street Light

Hitechled D3 series solar powered street light has an integrated Mono Crystalline solar panel, high efficient LED, intelligent battery management system, Long life lithium battery and PIR motion sensor.


The D3 all-in-one solar street light special feature

● Wing-like frame design.
● Adjustable bracket design.
● Unique Innovative drawer function design.
● Rust-proof, dust-proof, water-proof.
 ● Provides flexible solutions for the complex project requirements.


D3 series all in one solar street light are widely used for Road streets, Plaza, Parking Lot, Construction site, Emergency exit, Mine lot, Industrial park, Rural Area, Scenic Area, etc.
PV 40W to 70W
PV 100W to 135WHitechled D3 series all in one LED solar street light

Key Features

Hitechled D3 solar street light features

Product Diagram

Hitechled D3 integrated solar street light diagram


Why Choose HITECHLED Solar Street Light?

Smart All In One Integrated Technology

Elegant Modular design Easy installation & Minimum Maintenance Green Renewable Energy with high quality 24/7 pre-sales & d after-sales services
Smart IP67 Steady Controller
LiFePO4 Lithium-ion Battery
High Efficient Solar Panel
High Lumin LEDs
Professional Bat Wing Optical Lens
Complete Aluminum Frame Structure

Intelligent Steady State Controller
LiFePO4 Lithium-ion Battery


High Efficient Solar Panel
High Luminous Efficiency LED
Bat Wing + Spreadlight Lens
Complete Aluminum Frame Structure

Parameter

ITEM \ MODEL
Solar Panel
LED Lamp
Battery
Charging Time
Discharging Time
Mounting height
HT-SS-D340 HT-SS-D350 HT-SS-D360 HT-SS-D3100 HT-SS-D3120 HT-SS-D3135
40W Monocrystalline
Lifespan 25 years
50W Monocrystalline
Lifespan 25 years
60W Monocrystalline
Lifespan 25 years
100W Monocrystalline
Lifespan 25 years
120W Monocrystalline
Lifespan 25 years
135W Monocrystalline
Lifespan 25 years
40pcs CREE 3030 Modular LED Lamp
2,000~3,000lm, Lifespan 50,000hrs
50pcs CREE 3030 Modular LED Lamp
3,500~4,500lm, Lifespan 50,000hrs
96pcs CREE 3030 Modular LED Lamp
4,000~5,500lm, Lifespan 50,000hrs
96pcs CREE 3030 Modular LED Lamp
6,000~8,500lm, Lifespan 50,000hrs
144pcs CREE 3030 Modular LED Lamp
8,000~10,000lm, Lifespan 50,000hrs
144pcs CREE 3030 Modular LED Lamp
9,000~13,000lm, Lifespan 50,000hrs
231WH Lithium Ion Battery
>2000cycles,more than 5 years
308WH Lithium Ion Battery
>2000cycles,more than 5 years
346WH Lithium Ion Battery
>2000cycles,more than 5 yearsm
538WH Lithium Ion Battery
>2000cycles,more than 5 years
614WH Lithium Ion Battery
>2000cycles,more than 5 years
768WH Lithium Ion Battery
>2000cycles,more than 5 years
6~7hours 6~7hours 6~7hours 6~7hours 6~7hours 6~7hours
Full power >10hrs
Dimming mode 3 to 5 days
Full power >10hrs
Dimming mode 3 to 5 days
Full power >10hrs
Dimming mode 3 to 5 days
Full power >10hrs
Dimming mode 3 to 5 days
Full power >10hrs
Dimming mode 3 to 5 days
Full power >10hrs
Dimming mode 3 to 5 days
4-6m(suggested) 5-6m(suggested) 5-7m(suggested) 6-8m(suggested)
PIR sensor control <8m; Time control >8m
6-10m(suggested)
PIR sensor control <8m; Time control >8m
6-12m(suggested)
PIR sensor control <8m; Time control >8m
  • Video Introduction

How does it work?

The solar panel converts sunlight into electricity and stored in Lithium Ion battery via controller, the LED light will work at night automatically under the light sensor control, and provide light for the different areas. It will light in about 30% saving-mode when standby, and switches to full power mode when PIR sensor detects movement. The full power mode will last about 30s (after the last motion detected) and then switches back to low power mode until new motion detected. It can be also pre-programmed by time schedule without motion sensor as well. Say 1st one hour @ 20% illumination, next 4hrs @ full brightness, the rest hours @ 30% illumination. The intelligent system will control the lamp according to the battery capacity and environment.
